Cobalt Strike Redirectors using Apache-SSL

Overview

Redirectors are systems designed to proxy traffic from a target network to private attack infrastructure. They play a vital role in ensuring operational security and serve several key purposes:

1. Preventing Unauthorized Access

Redirectors act as a shield, preventing unauthorized parties from accessing the underlying attack infrastructure. They can:
Only allow authorized users or systems to connect to the actual infrastructure.
Make the infrastructure appear harmless or unrelated to its real purpose, deterring unwanted attention.

2. Shaping How the Infrastructure Appears

Redirectors control how the target perceives the infrastructure by:
Modifying content, headers, or other elements to make traffic appear legitimate and unsuspicious.
Mimicking well-known platforms or architectures to blend in and avoid detection.

3. Safeguarding the Attack Chain

By acting as a buffer, redirectors help ensure that the overall attack chain remains intact, even if a part of it is exposed. They achieve this by:
Keeping different parts of the infrastructure separate to minimize the risk of exposure.
Hiding communication patterns to make it harder to trace or identify the destination.
Providing a way to swiftly redirect traffic to backup systems if a redirector is compromised.

In red team operations, penetration testing, or other offensive security scenarios, redirectors are essential. They offer a blend of protection, control, and flexibility, making them a cornerstone of effective attack frameworks.

4. Cobalt Strike Redirectors using Apache-SSL

Step – 01

On the cobalt strike team server, we’ve to generate two files. public.crt and private.key.

root@teamserver: openssl req -new -newkey rsa:4096 -x509 -sha256 -days 365 -nodes -out public.crt -keyout private.key

Once the command is executed, you will be presented with the below prompts.

Country Name (2 letter code) [AU]:
State or Province Name (full name) [Some-State]:
Locality Name (eg, city) []:
Organization Name (eg, company) [Internet Widgits Pty Ltd]:
Organizational Unit Name (eg, section) []:
Common Name (e.g. server FQDN or YOUR name) []: 172.16.100.3
Email Address []:

Here the common name can be the domain you own. for my case I’m just using the ip of my teamserver.

now copy both the files from your teamsever to the redirector machines /etc/apache2/ssl by creating an ssl folder.

Step – 02

root@redirector1: sudo apt install apache2

root@redirector1: sudo a2enmod ssl rewrite proxy proxy_http

root@redirector1:~# mkdir -p /etc/apache2/ssl

root@redirector1: sudo nano /etc/apache2/sites-available/default-ssl.conf

Example of default-ssl.conf

<IfModule mod_ssl.c>
    <VirtualHost *:443>
        ServerAdmin webmaster@localhost
        DocumentRoot /var/www/html

        SSLEngine on
        SSLProxyEngine on
        SSLProxyCheckPeerCN off
        SSLCertificateFile /etc/apache2/ssl/Your-Team-server.crt
        SSLCertificateKeyFile /etc/apache2/ssl/Your-Team-server.key

        <Directory /var/www/html>
            Options Indexes FollowSymLinks MultiViews
            AllowOverride All
            Require all granted
        </Directory>

        ErrorLog ${APACHE_LOG_DIR}/error.log
        CustomLog ${APACHE_LOG_DIR}/access.log combined
    </VirtualHost>
</IfModule>

Make sure to have these in the default-ssl.conf SSLEngine on SSLProxyEngine on SSLProxyCheckPeerCN off

root@redirector1: sudo systemctl restart apache2

Now open a browser and open https://redirector1. you should see apache now running with SSL.

Quick thing to check in here if you’ve the right certificate is that by checking the cert. your should see your team-server ip or the FQDN in the certificate.

Step – 03

Now for the team-sever to communicate with our apache ssl. As cobalt-strike is written in java, the public certificate and private key need to be imported into a Java KeyStore.

First, we need to combine the separate public and private files into a single PKCS12 file.  Set the password to anything you want, but remember it.

root@teamserevr: openssl pkcs12 -inkey private.key -in public.crt -export -out tserver.pkcs12

You will be prompter to enter password:

Enter Export Password:
Verifying - Enter Export Password:

Do enter the password you can remember. Once done, you’ll see a file called tserver.pkcs12

That PKCS12 file can then be converted to a Java KeyStore using the keytool utility.

root@teamserevr: keytool -importkeystore -srckeystore tserver.pkcs12 -srcstoretype pkcs12 -destkeystore tserver.store

You’ll be prompted asking to enter the password. You can use the same password as before. make sure you remember it as we’ll be using it in the Malleable-C2-Profiles.

The password of this new store can be the same or different.  At this point, the .pkcs12 file can be deleted.  The new Java KeyStore needs to be referenced in a Malleable C2 profile before it can be used.

https-certificate { set keystore “tserver.store”; set password “password”; }

The Cobalt Strike Team Server expects the KeyStore to be in the same directory as itself.  Launch the Team Server with the updated profile.

root@teamserver: ./teamserver IP-address passwword@123 apt.profile
